8 TB 3,5" SATA HDD
7200 rpm, 2,5 mil. Hours MTBF
Гаранционен срок: 60 месеца
Производител: Synology
|
Hardware Specifications |
HAT5300-4T |
HAT5310-8T |
HAT5300-12T |
HAT5300-16T |
HAT5310-18T |
|
|---|---|---|---|---|---|---|
| General | Capacity | 4 TB | 8 TB | 12 TB | 16 TB | 18 TB |
| Form Factor | 3.5" | 3.5" | 3.5" | 3.5" | 3.5" | |
| Interface | SATA 6 Gb/s | SATA 6 Gb/s | SATA 6 Gb/s | SATA 6 Gb/s | SATA 6 Gb/s | |
| Sector Size | 512e | 512e | 512e | 512e | 512e | |
| Performance | Rotational Speed | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm |
| Interface Speed | 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s | 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s | 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s | 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s | 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s | |
| Buffer Size | 256 MiB | 256 MiB | 256 MiB | 512 MiB | 512 MiB | |
| Maximum Sustained Data Transfer Speed (Typ.) | 243 MiB/s | 248 MiB/s | 242 MiB/s | 262 MiB/s | 268 MiB/s | |
| Reliability | Mean Time to Failure (MTTF) | 2 million hours | 2 million hours | 2.5 million hours | 2.5 million hours | 2.5 million hours |
| Workload Rating | 550 TB Transferred per Year | 550 TB Transferred per Year | 550 TB Transferred per Year | 550 TB Transferred per Year | 550 TB Transferred per Year | |
| Warranty | 5 Years | 5 Years | 5 Years | 5 Years | 5 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) | |||||
| Power Consumption | Supply Voltage | 12 V (± 10%) / 5 V (+10/-7%) | 12 V (± 10%) / 5 V (+10/-7%) | 12 V (± 10%) / 5 V (+10/-7%) | 12 V (± 10%) / 5 V (+10/-7%) | 12 V (± 10%) / 5 V (+10/-7%) |
| Active Idle (Typ.) | 4.07 W | 5.61 W | 4.25 W | 4.00 W | 4.16 W | |
| Random Read / Write (4KB Q1) (Typ.) | 7.76 W | 9.29 W | 7.83 W | 7.63 W | 8.35 W | |
| Notes | Power consumption may differ according to configurations and platforms. | |||||
| Temperature | Operating | 5°C to 60°C (41°F to 140°F) | 5°C to 60°C (41°F to 140°F) | 5°C to 60°C (41°F to 140°F) | 5°C to 60°C (41°F to 140°F) | 5°C to 60°C (41°F to 140°F) |
| Non-operating | -40°C to 70°C (-40°F to 158°F) | -40°C to 70°C (-40°F to 158°F) | -40°C to 70°C (-40°F to 158°F) | -40°C to 70°C (-40°F to 158°F) | -40°C to 70°C (-40°F to 158°F) | |
| Shock | Operating | 686 m/s2 {70 G} (2 ms duration) | 686 m/s2 {70 G} (2 ms duration) | 686 m/s2 {70 G} (2 ms duration) | 686 m/s2 {70 G} (2 ms duration) | 686 m/s2 {70 G} (2 ms duration) |
| Non-operating | 2,940 m/s2 {300 G} (2 ms duration) | 2,450 m/s2 {250 G} (2 ms duration) | 2,450 m/s2 {250 G} (2 ms duration) | 2,450 m/s2 {250 G} (2 ms duration) | 2,450 m/s2 {250 G} (2 ms duration) | |
| Vibration | Operating | 7.35 m/s2 {0.75 G} (5 to 300Hz), 2.45 m/s2 {0.25 G} (300 to 500 Hz) | 7.35 m/s2 {0.75 G} (5 to 300Hz), 2.45 m/s2 {0.25 G} (300 to 500 Hz) | 7.35 m/s2 {0.75 G} (5 to 300Hz), 2.45 m/s2 {0.25 G} (300 to 500 Hz) | 7.35 m/s2 {0.75 G} (5 to 300Hz), 2.45 m/s2 {0.25 G} (300 to 500 Hz) | 7.35 m/s2 {0.75 G} (5 to 300Hz), 2.45 m/s2 {0.25 G} (300 to 500 Hz) |
| Non-operating | 29.4 m/s2 {3.0 G} (5 to 500 Hz) | 29.4 m/s2 {3.0 G} (5 to 500 Hz) | 29.4 m/s2 {3.0 G} (5 to 500 Hz) | 29.4 m/s2 {3.0 G} (5 to 500 Hz) | 29.4 m/s2 {3.0 G} (5 to 500 Hz) | |
| Altitude | Operating | -305 m to 3,048 m | -305 m to 3,048 m | -305 m to 3,048 m | -305 m to 3,048 m | -305 m to 3,048 m |
| Non-operating | -305 m to 12,192 m | -305 m to 12,192 m | -305 m to 12,192 m | -305 m to 12,192 m | -305 m to 12,192 m | |
| Relative Humidity | Operating | 5% to 90% R.H. (No condensation) | 5% to 90% R.H. (No condensation) | 5% to 90% R.H. (No condensation) | 5% to 90% R.H. (No condensation) | 5% to 90% R.H. (No condensation) |
| Non-operating | 5% to 95% R.H. (No condensation) | 5% to 95% R.H. (No condensation) | 5% to 95% R.H. (No condensation) | 5% to 95% R.H. (No condensation) | 5% to 95% R.H. (No condensation) | |
| Others | Size (Height x Width x Depth) | 26.1 mm x 101.85 mm x 147 mm | 26.1 mm x 101.85 mm x 147 mm | 26.1 mm x 101.85 mm x 147 mm | 26.1 mm x 101.85 mm x 147 mm | 26.1 mm x 101.85 mm x 147 mm |
| Weight | 693 g | 720 g | 720 g | 720 g | 720 g | |
| Certification |
|
|
|
|
|
|
|
Compatibility |
||||||
| Applied Models | ||||||
Производител:
SYNOLOGY
