L3 Switching Features | VRRP: Version v2/v3, Max 64 groups |
L3 Switching Features | Max 1,024, IPv6: Max 512 |
Интерфейс | 6× 10G SFP+ Slots |
VLAN | Voice VLAN |
Quality of Service | Voice VLAN |
Захранване | Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz) |
Интерфейс | 1× USB Type-C Console Port |
Интерфейс | 48 10/100/1000Mbps RJ45 Ports |
Ethernet портове | 6× 10G SFP+ Slots |
ХИТ | N |
Наличност | Ограничена - под 10 бр. |
Експлоатационни качества | Switching Capacity 216 Gbps per Unit |
Експлоатационни качества | Packet Forwarding Rate 160.7 Mpps |
L3 Switching Features | Static Routing |
Работна температура | -5 °C to 50 °C (23 °F to 122 °F) @ 300 meters |
L2 Switching Features | Static Link Aggregation |
VLAN | Max. 4K VLAN Groups |
L3 Switching Features | Max 1,000 Manual Binding Entries |
L2 Switching Features | Multicast Filtering |
Интерфейс | 1× RJ45 Management Port |
L2 Switching Features | IGMP Snooping |
Quality of Service | Class of Service |
L2 Switching Features | RSPAN |
L3 Switching Features | Static ARP: 512 static entries |
Софтуерни функции | VLAN |
Критерии за валидност на гаранцията | Гаранционна карта/Сериен номер |
VLAN | VLAN VPN (QinQ): Max 256 entries |
Размери дълбочина | 380 mm |
L2 Switching Features | L2 Multicast Table |
L3 Switching Features | IPv4: Max 256, IPv6: Max 256 |
Филтър Swich | 48 порта |
Размери ширина | 440 mm |
Ethernet портове | 1× RJ45 Management Port |
Системни изисквания | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
L3 Switching Features | RIP: Version v1/v2, Max 8,190 |
L2 Switching Features | Multicast |
L2 Switching Features | Port-based and VLAN-based Loopback Detection |
Размери височина | 44 mm |
L2 Switching Features | 802.3x Flow Control |
VLAN | Management VLAN |
Работна температура | -5 °C to 40 °C (23 °F to 104 °F) @ 3,000 meters |
Работна температура | -5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters |
Гаранция | 60 месеца |
Quality of Service | User-Defined OUI |
L3 Switching Features | IP Interfaces: |
Quality of Service | Bandwidth Control |
Софтуерни функции | Quality of Service |
L3 Switching Features | Relayed VLAN |
Експлоатационни качества | Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports) |
L2 Switching Features | Fast Leave |
L2 Switching Features | Static Multicast IP |
L2 Switching Features | MAC Address Table |
Brand | TP-LINK |
L3 Switching Features | Host Route Table: Max 6,100 entries |
Софтуерни функции | L2 and L2+ Features |
Софтуерни функции | L3 Features |
L2 Switching Features | Spanning Tree Protocol |
L3 Switching Features | Relayed Interface |
L3 Switching Features | ECMP: 256 entries, max 32 ECMP Nexthops per Destination |
L3 Switching Features | Proxy ARP |
L3 Switching Features | Dynamic ARP: 7,680 dynamic entries |
L3 Switching Features | OSPF: Version v2/v3; v2: Max 8,190, v3: Max 4,097 |
L3 Switching Features | DHCP Server: |
L2 Switching Features | PIM-DM, PIM-SM (IPv4) |
Вид на монтаж | Rackmount |
Интерфейс | 2× USB 2.0 Ports |
Интерфейс | 1× RJ45 Console Port |
L3 Switching Features | Max 64 IP Pools |
L2 Switching Features | Supports 2,048 IGMP groups |
Софтуерни функции | Security |
Софтуерни функции | Advanced Features |
Филтър Swich - PoE, SFP | SFP+ slots |
L2 Switching Features | MLD Snooping |
VLAN | VLAN VPN (QinQ) |
Експлоатационни качества | MAC Address Table 32 K |
Експлоатационни качества | Stacking Number: 8 |
Ethernet портове | 48× 10/100/1000 Mbps RJ45 Ports |
Ethernet портове | 1× RJ45 Console Port |
L2 Switching Features | Multicast VLAN Registration (MVR) |
Quality of Service | Smoother Performance |
Работна влажност | 10%~90% без кондензация |
VLAN | MAC VLAN Entries: 200 |
L2 Switching Features | ERPS |
VLAN | Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries |
VLAN | GVRP |
Влажност на съхранение | 10%~90% без кондензация |
L3 Switching Features | DHCP Server/Relay |
Експлоатационни качества | Jumbo Frame 9 KB |
Quality of Service | Action for Flows |
VLAN | Private VLAN |
VLAN | 802.1q Tagged VLAN |
VLAN | Multicast VLAN |
Гаранционен срок: 60 месеца
Производител: TP-LINK
Производител:
TP-LINK
