Quality of Service | Support 802.1p CoS/DSCP priority |
Quality of Service | Support 8 priority queues |
Цвят | Черен |
IPv6 | TCPv6/UDPv6 |
L3 Switching Features | Static Routing |
IPv6 | IPv6 neighbor discovery (ND) |
VPN | VLAN VPN (QinQ) |
Критерии за валидност на гаранцията | Гаранционна карта/Сериен номер |
+ Подарък | N |
IPv6 | Static IPv6 Routing |
IPv6 Applications | Tracert6 |
L3 Switching Features | DHCP VLAN Relay |
L3 Switching Features | DHCP Server/Relay |
VLAN | VLAN VPN (QinQ) |
Експлоатационни качества | Packet Buffer Memory: 12Mbits |
Интерфейс | 4× 10G SFP+ Slots |
Вид на монтаж | Rackmount |
VLAN | Private VLAN |
IPv6 | IPv6 Interface |
L3 Switching Features | Static ARP |
Quality of Service | Smoother Performance |
Quality of Service | Queue scheduling: SP, WRR, SP+WRR |
Захранване | Dual power supplies |
IPv6 | Pv6 applications |
L2 Switching Features | 802.3x Flow Control |
IPv6 | IPv6 Dual IPv4/IPv6 |
Филтър Swich | 24 порта |
Управление/Management | Web-based GUI |
IPv6 | Path maximum transmission unit (MTU) discovery |
Ethernet портове | 24× 2.5 Gbps RJ45 Ports |
Работна температура | 0℃~45℃ (32–113 ℉) |
VLAN | Port-Based QinQ |
Интерфейс | 1× RJ45 Console Port |
Наличност | Ограничена наличност |
IPv6 Applications | IPv6 SSH |
Размери височина | 44 mm |
Охлаждане | Активно |
Интерфейс | 24× 2.5 Gbps RJ45 Ports |
Захранване | 220~240VAC, 50/60Hz |
L3 Switching Features | DHCP L2 Relay |
L3 Switching Features | Proxy ARP |
IPv6 Applications | Telnet(v6) |
VLAN | GVRP |
Гаранция | 60 месеца |
L2 Switching Features | One-to-One |
VLAN | VLAN Group |
IPv6 Applications | IPv6 SNMP |
L2 Switching Features | Many-to-One |
VLAN | Voice VLAN |
L3 Switching Features | 32 IPv4/IPv6 Interfaces |
VLAN | Selective QinQ |
Интерфейс | 1× Micro-USB Console Port |
IPv6 | IPv6 ACL |
IPv6 | Multicast Listener Discovery (MLD) Snooping |
Приложение | Rackmount |
IPv6 Applications | Ping6 |
VLAN | MAC VLAN: 30 Entries |
IPv6 | Internet Control Message Protocol (ICMP) version 6 |
IPv6 Applications | Http/Https |
L3 Switching Features | Gratuitous ARP |
L2 Switching Features | Link Aggregation |
Експлоатационни качества | Forwarding rate: 95.2 Mpps |
L2 Switching Features | Port Mirroring |
VLAN | Max. 4K VLAN Groups |
Работна влажност | 10%~90% без кондензация |
Мрежови характеристики | Switching Capacity: 128 Gbps |
IPv6 Applications | IPv6 TFTP |
Тип | Управляем |
VLAN | Protocol VLAN: Protocol Template 16, Protocol VLAN 16 |
Quality of Service | Bandwidth Control |
L2 Switching Features | Gratuitous ARP |
Експлоатационни качества | MAC Address Table -16k |
VLAN | 802.1q Tagged VLAN |
IPv6 Applications | DHCPv6 Client |
Quality of Service | Action for Flows |
Тип | JetStream |
Филтър Swich - PoE, SFP | SFP+ slots |
Филтър Swich - PoE, SFP | PoE+ |
Филтър Swich - PoE, SFP | PoE++ |
L2 Switching Features | CPU Mirroring |
Влажност на съхранение | 5%~90% без кондензация |
Brand | TP-LINK |
Гаранционен срок: 60 месеца
Производител: TP-LINK
Производител:
TP-LINK
