Hi-PoE Суич 10/100, 8 ports + 2 Uplink, 2.0Gbps IEEE802.3af/at, 120W, 250m
|
Product Name |
8
Ports Hi-POE Switch(8+2) |
|
Data Pin |
1/2+,3/6- |
|
Power Supply Type |
Build in, 1/2+,3/6 |
|
Max PoE Output |
1-7th ports:30W |
|
Max PoE Output |
8th port:60W |
|
Connector |
8*10/100Mbps POE port,2*10/100Mbps uplink port |
|
Network Medium |
Cat5 (UTP) or more |
|
Technology |
|
|
Network
Standards |
IEEE
802.3i 10BASE-T IEEE 802.3u
100BASE-TX IEEE
802.3x Flow Control IEEE 802.3af
Power over Ethernet |
|
PoE
power |
30W
1-7th ports(IEEE802.3af/at) 60W
8th port(IEEE802.3af/at/bt) Wiring:
Data & power provided over pairs 1/2 and 3/6 |
|
Processing
types |
Store-and-forward Half-duplex
back pressure and IEEE 802.3x full-duplex flow control |
|
Address
database Table Size |
1K
MAC address |
|
Backboard
Bandwidth |
2Gbps |
|
Network
Latency |
Less
than 20us for 64 byte frames in store-and-forward mode for 100Mbps to 100Mbps
transmission |
|
Power |
|
|
Input |
AC
110-240V, 50/60 Hz |
|
Overload
current protection |
Present |
|
Mechanical |
|
|
Casing |
Metal |
|
Installation |
Desktop |
|
Interface |
|
|
LED
Indicators |
System:
Power Per
port: Link, PoE active |
|
Environment
specification |
|
|
Operating
temperature |
-10-55℃ |
|
Storage
temperature |
-40-70℃ |
|
Operating
humidity |
90%
maximum relative humidity, non-condensing |
|
Storage
humidity |
95%
maximum relative humidity, non-condensing |
|
Regulatory Approval |
|
|
Certificate |
CE/CCC |
|
Warranty |
2
years |
|
Dimensions |
202*140*45mm(L*W*H) |
|
Weight |
1Kg |
